TS 120A Electronic Speed Controller (SK300044)

TS120A
Advanced Timing System

Toro TS 120A ESC for 1/10th Scale Car is designed for the use with 2S to 3S LiPo battery packs, has a 3.5T motor limit and features a 6V/3A BEC system. This feature does away with the need to use a separate receiver battery pack.



Less Resistance, Less Heat, More Efficiency

10 User Modifiable Profiles

The users could set and store 10 sets of profiles in the ESC. These data could be called out at any time without any special program setting. All the setting can be exported or imported so that the user could compare and analyze.

Safety Features

Firmware Update

The firmware can be updated by connecting the ESC to a PC or a smart phone.

Programming Methods

The ESC can be programmed with a PC connected with SKYLINK (SK-600013)
The ESC can be programmed with a smart phone via Bluetooth Module (SK-600058)
The ESC can be programmed with the PROGBOX (SK-600046)

Precise Programmable Items

Advanced Timing System
Users could set the turbo and boost timing which can improve the motor RPM to get its best performance.

Well-performed Throttle and Brake Control Function

Users could set the punch/brake control rate by point or customize the throttle/brake curve by themselves,and different customers' request for linear and power all can be met.
TECHNISCHE DATEN
Constant/Burst Current 120A / 760A
Motors Sensor & Sensorless Brushless Motors
Cars 1/10 and 1/12 Buggy & Truck
1/10 and 1/8 Crawlers
Motor Limits 5-6S NiMH or 2S LiPo: ≥3.5T (1/10 Buggy), ≥5.5T (1/10 Truck)
8-9S NiMH or 3S LiPo: ≥5.5T (1/10 Buggy), ≥8.5T (1/10 Truck)
Resistance 0.0003 Ohm
Battery Cell Count 4-9S NiMH or 2-3S LiPo
BEC Output 6V 3A, Linear
Fan 5V 0.2A, Max. 12.6V
Weight 45g (without wires)
Dimensions (LxWxH) 39x38x20mm
