SOKAR FPV RTR Drone (SK910004)
Ready to Fly
SKYRC Sokar FPV Drone is a high performance quadcopter with FPV camera, video transmitter, video monitor and remote controller. Lipo battery and charger are included also. You just need to recharge the battery and can start flying.
Let's meet your Sokar FPV Drone now ...
TECHNICAL DATA
| Flight Controller MPU | Invensense 6050, 3 Axis Gyro, 3 Axis Accelerometer |
|---|---|
| Flight Controller CPU | STM32F031K4 32-bit ARM Processor |
| Video Tx | |
| Transmitter Module | 5.8GHz Module |
| Channels | 6 Programmed via Dipswitch |
| Frequency | 5845, 5825, 5805, 5785, 5765, 5745 MHz |
| Power Output | 25mW |
| Antenna | Cloverleaf Antenna |
| Power System | |
| Propellers Size | 5" |
| Brushless Motors | 2204-2300KV |
| Battery | LiPo 2000mAh 3S 30C |
| ESC Ratinge | 12A continuous, 17A peak |
| Flight Characteristics | |
| Flight Time | 12 Minutes, Also Depends Upon Flight Style |
| Maximum Range | Highly dependent on battery, and flying style |
| Video Camera | |
| Sensor | 300,000 Pixel |
| Lens | FOV (Field Of View) 135° |
| FPV Monitor | |
| Size | 4.3" TFT LCD |
| Resolution | 480x272 |
| Channel | 6 Channels |
| Frequency | 5845, 5825, 5805, 5785, 5765, 5745 MHz |
| Weight and Size | |
| Weight(FPV Drone) | 405g(without battery)MHz |
| Weight(Remote Controller) | 614g |
